1965 Suzuki K11
(Vin No: )
Color: Blue
Miles when purchased: unknown
Specifications | Photos |
The bike was purchased from a family
friend in 1966 and has remained in the family for over 30 years.
It is an 80cc 2 stroke engine requiring a mixture of gas and oil. Its
top speed when new was 65mph.
It is in running condition, but is currently being restored.
SUZUKI K11 SPECIFICATIONS
Engine
Type: Air-cooled, 2-stroke, single cylinder
Bore and stroke: 45mm x 50mm
Displacement: 79cc
Compression ratio: 6.7
Lubrication: Petrol : oil 20:1
Carburettor: VM 17 SC
Starting system: Kick
Performance
Max. output: 7.3 hp/7,000rpm
Max. speed: 95 km/h (59.5 mph)
Max. torque: 0.75 kgm/6,000 rpm
Climbing ability: 16” 30
Fuel consumption: 65 km/litre (153 miles/US gallon)
Transmission
Type: 4-speed foot operated with constant-mesh Return change type
Primary ratio: Gear 3.84
Secondary ratio: Chain 2.31
Clutch: Multiple wet disk
Dimensions
Length: 1,830 mm
Width: 613 mm
Height: 930 mm
Wheelbase: 1,160 mm
Ground clearance: 135 mm
Dry weight: 70 kg (154.32 lbs)
Other
Frame: Pressed steel, back-bone type
Front brake type: Internal expanding hand brake
Rear brake type: Internal expanding foot brake
Tires: 2.50” – 17” – 4PR
Front suspension: Telescopic oil damper
Rear suspension: Pivot swing oil damper
Fuel tank capacity: 6.5 liter (1.72 US gallon)
|
