- Alphanumeric display
- 40 memory channels
- 5 watt output with standard battery
- CTCSS encode+decode and DCS
- 13.8 VDC direct input with battery charge feature
- Direct frequency input
- S-meter
- Autodialer
- Cable Cloning
- Computer programmable (third party software required)
- MARS/CAP capability (DJ-195T/196T)
- Additional features, including theft alarm!
- Back-lit keypad
|
Specifications: |
|
| General | |
| Freq. RX original status: | 130 to 174 F2 F3 only |
| Freq. TX: | 144-147.995 |
| Freq. Stability: | +/-5ppm(-10 to +60c) |
| Antenna Imp: | 50 ohm unbalanced |
| Supply Voltage: | DC 13.8V rated DC 6.0min to 16V max |
| Ground: | Negative GND |
| Current consumption at 13.8V external source: |
TX 5W 1.2A approx. RX 200mA approx/300mW RX squelched 50mA approx. RX Batt.Save on 20mA app. |
| Operating Temp. range: | -10 to +60 degrees C. |
| Dimention w/o projection: | 56(W) x 124(H) x 40 (D) |
| Transmitter | |
| Output power: | 5W 13.8V or EBP48N Low=0.5W |
| Modulation: | Variable reactance |
| Max. Deviation: | n/a |
| Spurious emission: | less than -60db |
| Microphone Imp: | 2k ohms approx. |
| Receiver Circuit: | Double superheterodyne |
| 1st IF freq: | 21.7Mhz |
| 2nd IF freq: | 450khz |
| Sensitivity 12db SINAD: | better than -8dbu (0.2uV or less) |
| Selectivity except WFM: | more than -6db/12khz less than -60db/28khz |
| Image/spurious response: | less than -60db |
| AF out at 10% distort.13.8V: | Max 300mW |
| AF impedance: | 8 ohms |
| Standard Features | |
| Expandible RX range: | none |
| MARS/CAP mod: | Yes |
| DTMF: | tone encode |
| DCS SQ: | enc/dec |
| CTCSS SQ: | Enc/Dec 39tones |
| Memory channels: | 40ch non expandible |
| Auto Dialer memory: | memory 9 memories, max 16 characters/memory |
| Call channel: | Yes |
