It operates in analog and digital modes so you can ease into the realm of DMR at your leisure without leaving the comfort of good old analog. It operates on 400-480MHz frequencies (UHF model) or 136-174MHz VHF (VHF model) at up to 5 watts and uses Time-Division Multiple-Access (TDMA) digital technology to double the number of users on a single 12.5kHz channel at either high or low power.
- 1000 Channels
- 400-480MHz UHF Frequencies (UHF Model)
- 136-174MHz VHF Frequencies (VHF Model)
- Built-in CTCSS/DCS
- 5W/1W Output Power
- Repeater Capable
- Priority Scan Voice Prompt Complying with digital protocol ETSI TS102 361-1.-2.-3
- AMBE+2™ Digital Vocoder
- Uses Li-ion Rechargeable Battery Packs
- Rechargeable Li-ion Battery Pack Included
- Includes Charger
- Emergency Alarm
- VOX
- Encryption (Digital Mode Only)
- Private Call/Group Call/All Call
- Cloning Capable
- Text messages in digital mode
- Talk Around
- Channel Scan
- Priority Scan
- Lone Worker Mode
- LED Status Light
- Color LCD display
- DTMF decoding and encoding
- Lighted DTMF Keypad
- Hi/Low Power Selectable
- Signal Strength Indicator
- Battery Meter
- Low Battery Alert
- Battery Saver
- Programmable Multifunction Key
- PC Programmable (Optional Software and Cable Required)
- Timeout Timer
- Keypad Lock
- Audible Button Beeps
- Clock
- Drop-In Charge Capable
- IP54 Water Resistant
- Audio Accessory Connector
- Stun/Kill/Activate
- One Year Manufacturer Warranty
|
Specifications: |
|
| General | |
| Frequency Range: | 400-470MHz |
| Channel No.: | 1000 |
| Antenna impedance: | 50Ω |
| Operating Voltage: | 7.5 vDC |
| Operating Temperature: | -30°C~+60°C |
| Dimension(W x H x D): | 128x61x38mm |
| Battery: | 1700mAh Li-ion |
| Transmitter Output power: | ≥5W(H; ≥1W(L) |
| Vocoder type: | TDMA |
| Frequency Stability: | ± 1.0 PPM |
| Adjacent channel power: | ≤-60dB |
| Spurious Radiation Antenna: | 9KHz-1GHz ,≤ -36dBm 1GHz-12.75GHz ,≤-30dBm |
| Hum and noise: | -40dB @12.5KHz 4 |
| Receiver Digital sensitivity: | 0.3uV/-117.4dBm(BER 5%); 0.22uV/-100dBm(BER 1%) |
| Audio distortion: | 3%(TYPE) |
| Audio power: | 1W |
| Audio response: | =1dB-3dB |
| Adjacent Channel Selectivity: | Tia603C:65dB,ETSI:60dB |
| Spurious Tia603C: | 75dB,ETSI:70dB |
| Channel rejection: | ≥-12 dB |
