Features:

• APRS (Automatic Packet/Position Reporting System)
  Using APRS, the TH-D7AG lets you transmit your co-ordinates to a friend, who can then pinpoint your position using a map on a computer. APRS software has been developed for a variety of platforms; however, what makes the Data Communicator so special is that it enables APRS operation without requiring a computer. And when you receive your friend's positional data, you can display latitude/longitude, direction and distance on your own Data Communicator.
• Positional/directional data
   Just hook up to a GPS receiver and you can transmit your position for automatic calculation of distance, current speed and heading with icons, short comments or fixed messages. Manual input of latitude/longitude is also permitted.
• Versatile massaging
  Transmit alpha messages (up to 45 characters) and bulletins. Alternatively, shorts comments (up to 20 characters) and fixed massages (8 patterns) can be sent together with your positional data.
• Station list
  Store received APRS data in up to 40 memory channels.
• Grid square locator display
• TX interval (0,5/1/2/3/5/10/20/30 min.)
• Packed pass selection for DigiPeat
• Weather station, Power Height Gain data (fixed stations) & Object data reception
• Text superimpose function
  Add your call sigh, RSV reports, messages (Eight text colors available).
• VC shutter
  You can control a connected Visual Communicator (VC-H1) from your Data Communicator to initiate transmission
• Fast FM
  This high-speed transmission mode lets you send an image in 14 secs (approx.).
• SSTV transmission mode selection (9 modes)
  You can use any of the 8 standard SSTv modes, in addition to Fast FM.
• Dual receive for voice & image transmissions (VHF only)
  As well as allowing you to enjoy both APRS and SSTV (with Kenwood's VC-H1), the TH-D7E is fully equipped to provide the performance and features you would expect of the latest generation of dual-band transceivers.
• Built-in 1200/9600bps TNC (packed, 1 frame,256 bytes) complaint with AX,25 protocol)
• High-speed (9600bps) PC-based packet communications for chat, BBS, ets
• Monitoring DX cluster
• Dual receive on same band (VHF only) for both voice and data (two frequencies simultaneously)
• Wide/narrow TX deviation (VHF only).
• Large (12 digits x 3 lines) dot-matrix LCD, mutiscroll key, menu mode & other user-friendly features
• 200 memory channels with 8-character mamory name input
• 16 backlist keys
• Built-in CTCSS plus 1750Hz tone burst (38 EIA-standard subtone frequencies)
• AIP (Advanced Intercept Point) (VHF only)
• 16-digit, 10 channel DTMF memory
• Auto repeater offset (144MHz)
• MIL-STD 810C/D/E water resistance/b>
• DC 13,8V input (built-in recharger)
• High-gain dual band antenna
